XQ20 Series Spare Parts (XQ20-225, XQ20-228, XQ20-233) for Oilfield Drilling Equipment

Introduction to XQ20 Series Spare Parts

For oilfield drilling operations, the stability and durability of spare parts directly determine the efficiency of drilling work and the safety of on-site operations. The XQ20 series spare parts, including core models such as XQ20-225 Roller, XQ20-228 Backup tong body, XQ20-233 Ball bearing, and more than 30 supporting components, are specifically designed to fit XYQ12 series, XQ20.1.1 series, and XYQ3C series drilling equipment. These parts are widely used in backup tongs, transmission systems, and sealing mechanisms of oilfield drilling rigs, solving the pain points of frequent part replacement, poor compatibility, and short service life that have long plagued drilling teams.

Our XQ20 series spare parts are produced in strict accordance with national standards such as GB/T71, GB/T891, GB/T276, and GB1235-76, with each component undergoing 12 strict quality inspections before leaving the factory. Backed by a professional R&D team with 18 years of experience in oilfield spare parts research and production, and certified by ISO 9001 and API 7K, our products have been tested and recognized in more than 50 oilfields at home and abroad, with a cumulative service life of over 800,000 hours in actual working conditions—far exceeding the industry average of 550,000 hours. We focus on providing cost-effective, high-reliability spare parts solutions for oilfield drilling companies, maintenance teams, and equipment operators, ensuring that drilling operations run smoothly without interruption.

Product Description & Core Advantages

1. Product Overview

The XQ20 series spare parts cover a complete range of components, including rollers (XQ20-225, XQ20-76), dies (XQ20-71(1), XQ20-71(2)), die seats (XQ20-72(1)-XQ20-72(8), XQ20-226), backup tong components (XQ20-227, XQ20-228, XQ20-254), bearings (XQ20-233, XQ20-236), fasteners (XQ20-75, XQ20-231, XQ20-249), and sealing parts (XQ20-243, XQ20-245). Each part is precision-machined using high-strength alloy materials and advanced heat treatment technology, ensuring perfect compatibility with the original equipment and stable performance in harsh oilfield environments.

2. Function & Pain Point Solutions

Every component in the XQ20 series is designed to address specific on-site pain points:

• XQ20-225 Roller & XQ20-74 Roller shaft: Solve the problem of rapid wear and jamming during high-load operation, with a surface hardness of HRC 62-65, which can withstand a maximum load of 1800N without deformation, avoiding frequent shutdowns for replacement.

• XQ20-228 Backup tong body: Made of integral forging technology, it solves the problem of cracking due to uneven force during tong operation, with a tensile strength of 860MPa, ensuring safe operation under high torque conditions.

• XQ20-233 Ball bearing (GB/T276): Adopts sealed structure design, preventing dust and drilling fluid from entering, solving the problem of bearing damage caused by harsh working conditions, and extending the service life to 12,000 hours.

• Sealing parts such as XQ20-243 Oring (GB/T3452.1): Made of high-temperature and oil-resistant rubber, it solves the problem of oil leakage in the hydraulic system, with a service life of 8,000 hours under 120℃ working temperature.

3. Structural Features

The XQ20 series spare parts have obvious structural advantages that adapt to the harsh working environment of oilfields:

• Integral forging structure: Key components such as backup tong body and gear shaft are made of integral forging, which improves the structural strength and reduces the risk of fracture, compared with cast parts, the service life is increased by 3,500 hours.

• Precision machining: All parts are processed by CNC machine tools with an error of less than 0.02mm, ensuring perfect fit with the original equipment, avoiding installation difficulties caused by size deviation.

• Corrosion-resistant coating: The surface of components such as rollers and die seats is coated with a special anti-corrosion layer, which can resist the corrosion of drilling fluid and underground gas, adapting to the humid and corrosive environment of oilfields.

• Standardized design: All fasteners and sealing parts comply with national standards such as GB/T71 and GB/T3452.1, which is convenient for on-site replacement and reduces the difficulty of spare parts management.

4. Applicable Working Conditions

The XQ20 series spare parts are specially designed for the harsh working conditions of oilfield drilling, and are applicable to:

• Deep well drilling: Adapt to the high temperature (up to 180℃) and high pressure (up to 70MPa) environment of deep wells, ensuring stable operation of components.

• Offshore oilfields: The anti-corrosion coating can resist the corrosion of seawater, suitable for offshore drilling platforms.

• Heavy oil exploitation: The high-strength material can withstand the impact of heavy oil viscosity, avoiding component damage caused by high load.

• Desert oilfields: The sealed structure prevents sand and dust from entering, ensuring the normal operation of bearings and other precision components.

5. Maintenance & Maintenance Suggestions

To extend the service life of XQ20 series spare parts and ensure stable operation, our engineers provide the following practical maintenance suggestions (based on 18 years of on-site experience):

• Regular inspection: Check the wear of rollers, dies, and other easily worn parts every 500 hours of operation; if the wear amount exceeds 0.5mm, replace them in time to avoid secondary damage to other components.

• Lubrication maintenance: Apply special lubricating grease to bearings, roller shafts, and other rotating components every 300 hours, and clean the old lubricating grease before applying, avoiding the mixing of impurities affecting lubrication effect.

• Storage precautions: Spare parts should be stored in a dry and ventilated warehouse, away from moisture and corrosive substances; the surface of metal parts should be coated with anti-rust oil to prevent rust.

• Installation tips: When installing die seats and other components, ensure that the installation position is accurate, and do not force installation to avoid thread damage or component deformation; after installation, test run for 30 minutes to check for abnormal noise or jamming.

• Avoid pitfalls: Do not use non-standard spare parts to replace XQ20 series components, as this will not only affect the compatibility but also increase the risk of equipment failure; do not overload the components beyond the rated load, which will shorten the service life.

We supply the following spare parts:

On-Site Fault Maintenance Cases

The following are 4 real on-site maintenance cases of XQ20 series spare parts, covering different oilfield locations and fault types, to help you better understand the practical application effect of our products:

Case 1: Karamay Oilfield, Xinjiang

Equipment model: XYQ12.B-35 drilling rig; Fault component: XQ20-225 Roller; Load: 1600N; Fault description: The roller was severely worn, resulting in jamming of the transmission system, and the drilling operation was interrupted. Maintenance measures: Replace with XQ20-225 Roller; Repair effect: The transmission system runs smoothly, the roller wear rate is reduced by 0.1mm per 100 hours, and the continuous operation time reaches 1,200 hours without failure. Customer feedback: "The new roller is more durable than the original one, which greatly reduces the number of shutdowns and improves drilling efficiency."

Case 2: Tarim Oilfield, Xinjiang

Equipment model: XQ20.2-3 backup tong; Fault component: XQ20-228 Backup tong body; Load: 2000N; Fault description: The backup tong body cracked during high-torque operation, posing a safety hazard. Maintenance measures: Replace with XQ20-228 Backup tong body (integral forging); Repair effect: The tensile strength reaches 860MPa, and it has been in stable operation for 8 months, with no cracks or deformation. Customer feedback: "The new backup tong body is very strong, and it can withstand high torque without damage, ensuring the safety of on-site operations."

Case 3: Shunbei Oilfield, Xinjiang

Equipment model: XYQ3C.B-23B hydraulic system; Fault component: XQ20-243 Oring 53×3.55; Load: 120MPa; Fault description: Oil leakage occurred in the hydraulic system due to aging of the Oring, affecting the normal operation of the backup tong. Maintenance measures: Replace with XQ20-243 Oring (GB/T3452.1); Repair effect: No oil leakage occurred after replacement, the system pressure is stable at 120MPa, and the Oring service life reaches 8,000 hours. Customer feedback: "The sealing effect is very good, and we no longer need to frequently check and replace the Oring, which saves a lot of maintenance time."

Case 4: Daqing Oilfield, Heilongjiang

Equipment model: XQ20.1.1-6 transmission system; Fault component: XQ20-233 Ball bearing; Load: 1500N; Fault description: The bearing was damaged due to dust entering, resulting in abnormal noise and reduced transmission efficiency. Maintenance measures: Replace with XQ20-233 Ball bearing (sealed structure) and clean the transmission system; Repair effect: The abnormal noise disappears, the transmission efficiency is restored to 98%, and the bearing has been in stable operation for 12,000 hours. Customer feedback: "The sealed bearing effectively prevents dust from entering, and the service life is much longer than the original bearing, which is very cost-effective."

FAQ (Frequently Asked Questions)

Purchase Guide & Conclusion

The XQ20 series spare parts, with their high durability, perfect compatibility, and strict quality control, have become the first choice for oilfield drilling companies to replace spare parts. Whether you need to replace worn rollers, backup tong components, bearings, or sealing parts, our XQ20 series can provide you with reliable solutions, helping you reduce maintenance costs, improve drilling efficiency, and ensure on-site operation safety.

All our products are backed by professional technical support and quality assurance, with each component marked with a unique quality inspection code for traceability. We provide comprehensive after-sales service, including technical guidance on installation and maintenance, to solve your worries in use. If you are looking for high-quality, cost-effective XQ20 series spare parts (XQ20-225, XQ20-228, XQ20-233, etc.) for your oilfield drilling equipment, please contact us to place an order. We will provide you with high-quality products and professional services to support your drilling operations to run smoothly.
