Replacement Parts for Hydraulic Tubing Tong Model XQ114/6B

Introduction: Solve Your XQ114/6B Tubing Tong Downtime Pain Points

For drilling teams, workover crews, and maintenance technicians who rely on the Yancheng Teda Hydraulic Tubing Tong Model XQ114/6B, unexpected equipment failure is more than an inconvenience—it’s a costly disruption. Every minute your XQ114/6B is out of service due to a worn pin, faulty seal, or damaged jaw can lead to delayed operations, increased labor costs, and missed production targets. We specialize in supplying 100% compatible replacement parts for the XQ114/6B hydraulic tubing tong, covering every critical component from the TONG DIES (P/N: Z6-73) to the HYDRAULIC MOTOR (P/N: Z6-137). Our parts are engineered to meet or exceed the original equipment manufacturer (OEM) standards, ensuring seamless fit, reliable performance, and extended service life—so you can keep your operations running smoothly, even in the harshest oilfield conditions.

Our core mission is to provide targeted solutions for your XQ114/6B maintenance needs. Whether you’re replacing a worn TONG JAW (2-7/8″, P/N: Z6-79) that’s causing pipe slippage, a faulty HAND CONTROL VALVE (P/N: Z6-138) that’s affecting operational precision, or a broken BRAKING SPRING (P/N: Z6-28) that’s compromising safety, we have the exact part you need. All our parts are manufactured in facilities compliant with API Spec 7K and SY/T 5074 standards—the industry’s gold standard for oilfield equipment components—and undergo rigorous testing to ensure they can withstand the high torque, pressure, and environmental stress of daily oilfield use. With over 15 years of experience supplying spare parts for Yancheng Teda equipment, we’ve built a reputation for reliability, with 28,000+ parts successfully installed across 40+ oilfields worldwide.

Product Overview: XQ114/6B Hydraulic Tubing Tong Replacement Parts

Core Purpose

The XQ114/6B hydraulic tubing tong is an open-type power tool designed for making up and breaking out tubing connections in well services, with a pipe size range of 2 3/8″ to 4 1/2″ for the master tong and 2 7/8″ to 4 1/2″ for the backup tong. Our replacement parts are specifically engineered to restore and enhance the performance of this critical equipment, addressing common pain points such as component wear, hydraulic leaks, operational jams, and safety hazards. From small fasteners like the COUNTERSUNK SCREW (P/N: Z6-21) to key functional components like the HYDRAULIC MOTOR (P/N: Z6-137), each part plays a vital role in ensuring the XQ114/6B operates at its rated torque (1650 N·m high gear, 6070 N·m low gear) and speed (62 rpm high gear, 17 rpm low gear).

Key Features & Functional Advantages

Every part we supply is designed to solve real-world problems for oilfield teams. Here’s how our components address your most pressing pain points:

• TONG DIES (2-3/8″ TO 2-7/8″, P/N: Z6-73): Made from hardened alloy steel with a special surface treatment, these dies prevent pipe slippage—a common issue that can damage tubing and cause dangerous operational failures. Our dies have a service life of 1,200+ make-up/break-out cycles, outperforming generic alternatives by 350+ cycles.

• HYDRAULIC MOTOR (P/N: Z6-137): Built to handle the XQ114/6B’s rated operating pressure of 11 MPa (1595 psi) and flow rate of 100 L/min (26 gpm), this motor eliminates the frustration of slow or unresponsive tong operation. It features a sealed bearing design that prevents hydraulic fluid contamination, reducing maintenance frequency by 40% compared to standard motors.

• MECHANICAL SEALS & OIL SEALS (e.g., Oil seal JH-T320103055 for DQ30): These seals prevent hydraulic fluid leaks, which can lead to reduced pressure, inefficient operation, and environmental damage. Our seals are made from high-temperature resistant material that can withstand operating temperatures up to 120°C, ensuring a leak-free service life of 8,000+ operating hours.

• RESET KNOB & SHAFT (P/N: B6-3, B6-4, Z6-49): These components ensure smooth and reliable resetting of the backup tong, eliminating jams that can halt operations. The knobs are ergonomically designed for easy operation, even with gloves, and the shafts are heat-treated to resist bending and wear.

• SPRINGS (PULLING SPRING P/N: Z6-123, BRAKING SPRING P/N: Z6-28): Manufactured with precision coil technology, our springs maintain consistent tension over 10,000+ cycles, preventing brake failure and ensuring the tong jaws clamp securely. They are corrosion-resistant, making them ideal for use in harsh, high-humidity oilfield environments.

Structural Characteristics

Our replacement parts are engineered to match the exact dimensions and specifications of the original Yancheng Teda components, ensuring a perfect fit with no modifications required. Key structural advantages include:

• All metal components (pins, shafts, screws) are made from high-strength alloy steel and undergo heat treatment to achieve a hardness of HRC 45-50, ensuring resistance to bending, wear, and impact.

• Hydraulic components (valves, motors) feature precision-machined internal parts with tight tolerances (±0.02 mm), ensuring smooth operation and consistent performance.

• Non-metallic components (seals, gaskets) are made from high-quality elastomers that are compatible with all standard hydraulic fluids, preventing swelling and degradation.

• Fasteners (screws, pins) are coated with a zinc-nickel plating to resist corrosion, extending their service life in saltwater or high-moisture environments.

Applicable Working Conditions

Our XQ114/6B replacement parts are designed to perform reliably in the most demanding oilfield conditions, including:

• Operating temperatures: -40°C to 120°C, suitable for both cold northern oilfields and hot desert environments.

• Pressure range: 0-15 MPa (0-2175 psi), exceeding the XQ114/6B’s rated operating pressure to handle peak loads.

• Environmental conditions: Resistant to dust, sand, mud, and saltwater, making them ideal for onshore and offshore well sites.

• Load capacity: Designed to handle the XQ114/6B’s maximum torque of 6070 N·m (4477 ft-lbs) in low gear, ensuring reliable performance during heavy-duty operations.

We supply the following spare parts:

On-Site Fault Repair Cases (4 Real Scenarios)

Our parts have been tested and proven in real oilfield conditions, solving critical downtime issues for teams worldwide. Here are four short, detailed case studies:

Case 1: Bohai Bay Oilfield, China – TONG DIES Wear Causing Pipe Slippage

Equipment: XQ114/6B hydraulic tubing tong (Yancheng Teda), Load: 4 1/2″ tubing, 5800 N·m torque, Problem: Generic dies worn after 850 cycles, causing pipe slippage and delayed operations. Solution: Replaced with our TONG DIES (P/N: Z6-73). Results: Die service life extended to 1250 cycles, no slippage reported, operation time reduced by 2 hours per well. Customer Feedback: “The new dies grip securely even under high torque—we’ve cut maintenance time in half and haven’t had a single slippage incident since installation.”

Case 2: Permian Basin, USA – HYDRAULIC MOTOR Failure

Equipment: XQ114/6B hydraulic tubing tong,Load: 3 1/2″ tubing, 4200 N·m torque, Problem: Original hydraulic motor failed after 6,500 operating hours, leading to 8 hours of downtime. Solution: Installed our HYDRAULIC MOTOR (P/N: Z6-137). Results: Motor operated continuously for 10,200 hours without failure, pressure maintained at 11 MPa (rated), speed consistent at 17 rpm (low gear). Customer Feedback: “The replacement motor is more reliable than the original—we’ve avoided costly downtime and saved over $12,000 in labor and replacement costs.”

Case 3: Daqing Oilfield, China – BRAKING SPRING Breakage

Equipment: XQ114/6B hydraulic tubing tong, Load: 2 7/8″ tubing, 3800 N·m torque, Problem: Braking spring (original P/N: Z6-28) broke during operation, causing the tong to fail to clamp, risking equipment damage. Solution: Replaced with our BRAKING SPRING (P/N: Z6-28). Results: Spring maintained consistent tension for 10,500 cycles, brake response time reduced to 0.3 seconds, no further breakages. Customer Feedback: “The spring is sturdier than the original—we feel safer knowing the brake will engage reliably every time.”

Case 4: Eagle Ford Shale, USA – HAND CONTROL VALVE Malfunction

Equipment: XQ114/6B hydraulic tubing tong, Load: 4″ tubing, 5200 N·m torque, Problem: Hand control valve (original P/N: Z6-138) stuck, preventing gear shifting and halting operations. Solution: Replaced with our HAND CONTROL VALVE (P/N: Z6-138). Results: Valve operates smoothly, gear shifting time reduced to 1.2 seconds, no stuck issues over 7,800 operating hours. Customer Feedback: “The replacement valve is more responsive—we can switch gears quickly and keep operations on schedule.”

Maintenance & Engineer’s Practical Tips

Maintenance Recommendations

• Inspect TONG DIES (P/N: Z6-73) and TONG JAW (P/N: Z6-79) every 100 make-up/break-out cycles for wear; replace if the tooth profile is worn down by more than 1.5 mm.

• Check hydraulic seals and oil seals (e.g., JH-T320103055) monthly for leaks; clean the seal surface with diesel and replace if cracks or swelling are found.

• Lubricate all pins, shafts, and roller components (e.g., ROLLER SHAFT P/N: Z6-76) every 50 operating hours with high-temperature grease (NLGI Grade 2) to prevent friction and wear.

• Test the HAND CONTROL VALVE (P/N: Z6-138) and HYDRAULIC MOTOR (P/N: Z6-137) weekly to ensure smooth operation; bleed air from the hydraulic system if pressure is inconsistent.

• Store spare parts in a dry, dust-free environment; avoid exposure to moisture or extreme temperatures to prevent corrosion.

Engineer’s Pitfall Reminders

Based on years of on-site experience, here are critical tips to avoid common mistakes that lead to component failure:

• Never use generic dies that don’t match the XQ114/6B’s specifications—they can slip, damage tubing, and even cause the tong to fail. Always use dies marked with P/N: Z6-73 for 2-3/8″ to 2-7/8″ tubing.

• Don’t over-tighten fasteners (e.g., COUNTERSUNK SCREW P/N: Z6-21)—over-tightening can strip threads or crack components. Follow the torque specification of 28 N·m for all XQ114/6B fasteners.

• Avoid using hydraulic fluid that doesn’t meet ISO VG 46 standards—low-quality fluid can cause valve jams and motor wear. Change hydraulic fluid every 2,000 operating hours.

• Don’t ignore unusual noises from the tong—grinding or squeaking often indicates worn roller shafts (P/N: Z6-76) or jaw rollers (P/N: Z6-78). Replace these components immediately to prevent further damage.

FAQ (Frequently Asked Questions)

Procurement Guide & Call to Action

When procuring replacement parts for your XQ114/6B hydraulic tubing tong, it’s critical to choose parts that are compatible, durable, and compliant with industry standards—this not only ensures smooth operations but also reduces long-term maintenance costs and safety risks. Our parts are the ideal choice for teams that value reliability, efficiency, and cost-effectiveness. We supply all the critical components you need, from small fasteners to key hydraulic parts, with a focus on solving your downtime pain points.

Whether you need a single TONG DIE (P/N: Z6-73) or a full set of spare parts for your XQ114/6B fleet, we have you covered. Our parts are available in stock, and we offer flexible procurement options to meet your project needs. Don’t let equipment failure slow you down—choose our high-quality replacement parts to keep your XQ114/6B hydraulic tubing tong operating at peak performance. Contact us today to discuss your part requirements and get the support you need to keep your oilfield operations on track.
