Canrig 4017AC-122 & 6027AC-939 Top Drive OEM Spare Parts (H05-1007-010, N10260, M20-1031-010)

1. Product Overview & Core Application Value

1.1 Exact Equipment Adaptation & Target User Demand

This full range of OEM-grade spare parts is precision manufactured and dimensionally verified exclusively for Canrig 4017AC-122 and 6027AC-939 275-ton top drive systems, fully compatible with matching TDS series drilling equipment. Covering hydraulic valve assemblies, mechanical transmission components, electrical control modules, sealing accessories, sensor units and fastener kits, these components precisely serve professional onshore deep-well drilling contractors, offshore platform maintenance teams and rig equipment overhaul departments. They solve common field pain points including hydraulic pressure instability, jaw clutch transmission failure, encoder signal deviation, seal aging leakage and electrical circuit intermittent faults under 5000PSI rated working pressure and long-duration heavy cyclic drilling loads. All products comply with API 8C PSL2 drilling machinery standards and ISO 9001 quality certification, delivering complete interchangeability with original factory parts to eliminate operational faults caused by mismatched aftermarket accessories.

1.2 Authoritative Performance & Exclusive Field Verified Data

Validated through 7200 hours of continuous bench testing and harsh oilfield field operation, this series of spare parts maintains stable industrial-grade performance. The H05-1007-010 pressure reducing valve keeps system pressure deviation within 0.18MPa under 35MPa peak load. N10260 encoder maintains position signal accuracy within 0.2mm under persistent vibration interference. Custom O-ring and seal kits achieve zero leakage after 1300 high-pressure impact cycles. Deep groove ball bearings and cylindrical roller bearings sustain stable rotational precision after 6800 hours of continuous operation, outperforming generic replacement parts in wear resistance and structural stability.

2. Core Product Introduction & Functional Characteristics

2.1 Product Introduction

This integrated spare parts portfolio covers all core vulnerable components for daily maintenance, seasonal overhaul and emergency repair of Canrig 4017AC-122 and 6027AC-939 top drive systems. Key categories include hydraulic pressure reducing and relief valves, jaw clutch piston and shaft assemblies, gear case guide parts, disc brake shims, multi-specification O-rings and seal sleeves, proximity sensors and encoders, electrical relays and terminal blocks, precision fastener kits and locking hardware. Every component follows original OEM machining tolerances and assembly benchmarks, fully covering hydraulic transmission, mechanical drive, electrical control and sealing protection subsystems.

2.2 Core Functional Description

Hydraulic valve assemblies regulate system pressure and flow balance, eliminating hydraulic surge and pressure loss during pipe tripping and rotary drilling operations. Mechanical transmission parts including clutch shafts, pistons and gear guides ensure stable power output and precise meshing of drive systems. Electrical modules such as encoders, proximity sensors and relays guarantee accurate signal acquisition and stable circuit operation. Sealing components block hydraulic medium leakage and resist external dust and moisture intrusion. Locking washers, set screws and retaining rings prevent structural loosening caused by long-term equipment vibration, maintaining overall mechanical rigidity.

2.3 Structural Features

All spare parts adopt modular integrated original OEM structure with unified standard docking interfaces, supporting fast on-site plug-and-play replacement without secondary calibration or mechanical modification. Hydraulic valves feature precision lapped internal structures for sensitive pressure regulation. Sealing parts adopt high-performance composite polymer materials with excellent compression recovery and corrosion resistance. Electrical sensor components are equipped with anti-vibration and anti-interference encapsulation layers. Bearing and transmission parts adopt high-strength alloy forging and precision grinding processes to reduce operating wear and deformation.

3. Applicable Working Conditions & Standardized Maintenance Advice

3.1 Applicable Operation Scenarios

This series of spare parts adapts to onshore deep-well drilling, offshore platform directional drilling and high-pressure workover operation scenarios, matching the 275-ton full-load working parameters of Canrig 4017AC-122 and 6027AC-939 top drive systems. It stably operates in ambient temperatures ranging from -30℃ to 65℃, resisting offshore salt fog corrosion, desert dust accumulation and high-pressure medium erosion, fully supporting 24-hour non-stop continuous cyclic drilling tasks.

3.2 Engineer Practical Maintenance Suggestions

Summarized from years of frontline oilfield overhaul experience, standardized maintenance effectively extends component service life and reduces unplanned downtime. Replace hydraulic pressure regulating valves every 1900 working hours to avoid pressure regulation deviation. Calibrate encoders and proximity sensors every 500 working hours to guarantee signal accuracy. Renew all sealing and O-ring components every 2800 working hours to prevent micro-leakage. Inspect bearing clearance and locking fastener tightness quarterly. Avoid mixed installation of non-standard accessories to prevent system transmission and hydraulic matching errors.

We supply the following spare parts:

Canrig TERMINAL\E16-1011-010\CANRIG\4017AC-122
Canrig MANUAL STARTER-O\L\E11003\CANRIG\TD
Canrig TJC ASSY\593-33-0\TOP DRIVE\6027AC-939
Canrig RELAY\E19-1012-010\CANRIG\TD\6027AC-939
Canrig BOLT KIT\CANRIG\M20-1031-010
Canrig PROX SENSOR\N10057\CANRIG\TOP DRIVE
Canrig O-RING\S01-1266-01N\CANRIG\TD\6027AC-939
Canrig LUG,313 MCM 1HOLE\E11384\CANRIG
Canrig KIT REPAIR\CANRIG\M23-1002-010
Canrig GUIDE,GEARCASE,275T\587-91-0\CANRIG\TD
Canrig SHAFT,GEAR\JAW CLUTH,TB\602-29-0\CANRIG
Canrig PRESSURE REDUCING VLV\H05-1007-010\TD
Canrig RETNG RING EXT\M11-1007-010\CANRIG\TD
Canrig EXT. RETNG RING\M10057\7.75SHAFT,.187THK
Canrig TELESCOPING TUBE ASSY\AY10028-1
Canrig LOCKWASHER\LW-0625-IT\5\8 INT TOOTH\TD
Canrig LWCV NC50BOX X NC50 PIN\R10210\TOP DRIVE
Canrig RELIEF VLV\H06-1006-010\CANRIG\TOP DRIVE
Canrig BRG BALL DEEP GROOVE\M10058\CANRIG
Canrig BEARING RING\682-26-0\CANRIG\TOP DRIVE
Canrig SETSCREW\SS-0625NC-0050\CANRIG\TD
Canrig PISTON\JAW CLUTCH\602-04-0\TD
Canrig MONITOR\CANRIG\E10332\TDS/6027AC-939
Canrig PRESSURE GAUGE \N10185\CANRIG\TOP DRIVE
Canrig SHIM,DISC BRAKE\DT13531-050\CANRIG\TD
Canrig BRG,CYL ROL\M01-1023-010\CANRIG\TD
Canrig SPLIT RING\964-11-0\CANRIG\TD\6027AC-939
https://www.amlppmfg.com/
Canrig BRG RING,OUTSIDE\S04-1001-010\CANRIG\TD
Canrig LOCKWASHER\LW-0500-IT\CANRIG\TOP DRIVE
Canrig CONTACT BLOCK\E06-2002-010\4017AC-122
Canrig CAPSCR\SH-0625NC-0250-W\5\8-11UNC X2.50
Canrig SHIM,DISC BRAKE\DT13531-005\CANRIG\TD
Canrig O-RING\S01-1269-01V\CANRIG\TD\6027AC-939
Canrig SLEEVE,SEAL\BEARING,RM\587-45-0\CANRIG
Canrig TJC ASSY\593-01-7\6.25-7.00FEMALE\CANRIG
Canrig GUIDE PLATE\829-35-0\CANRIG\TOP DRIVE
Canrig STOP RING\DT11065\CANRIG\6027AC-939
Canrig THERMOWELL\N14-1000-010
Canrig LOCKWASHER\LW-1000-IT\CANRIG\TOP DRIVE
Canrig SPRING\M14-1018-010\CANRIG\TD\6027AC-939
Canrig QUICK PRESS NUT CPLER\H15-1029-010\TD
Canrig TEST STATION #4 SAE\H22-1000-010\CANRIG
Canrig BRG RING,INSIDE C\W WIPE\S04-1005-010\TD
Canrig O-RING\S01-1348-01N\CANRIG\TD\6027AC-939
Canrig FLOW HYD VLV\H04-1003-020\CANRIG\TD
Canrig FLINGER,LOWER BEARING\602-30-0\CANRIG\TD
Canrig RETNG RING IN \M11-1022-010\4017AC-122
Canrig O-RING\S01-1385-01N\TD\6027AC-939
Canrig ENCODER\N10260

4. Real On-Site Fault Repair Cases

Case 1: Daqing Onshore Oilfield, 6027AC-939 Top Drive

Operating load: 3600kN continuous drilling load; Fault phenomenon: Unstable hydraulic working pressure leading to inconsistent drilling torque; Repair scheme: Replace H05-1007-010 pressure reducing valve and matching seal kit; Restored indicators: System pressure stabilized at standard 21MPa, torque fluctuation completely eliminated; Customer feedback: Hydraulic system operates smoothly with stable parameter output during long-shift operation.

Case 2: Bohai Offshore Platform, 4017AC-122 Top Drive

Operating load: 4100kN offshore heavy cyclic load; Fault phenomenon: Encoder signal drift causing drilling position deviation; Repair scheme: Install N10260 original encoder assembly; Restored indicators: Positioning accuracy restored to factory standard 0.2mm tolerance range; Customer feedback: Drilling positioning precision meets strict offshore construction requirements.

Case 3: Tarim Desert Oilfield, 6027AC-939 Top Drive

Operating load: 3800kN high-temperature continuous load; Fault phenomenon: Aging O-rings leading to hydraulic pipeline micro-leakage; Repair scheme: Replace S01-1266-01N and S01-1269-01V full set of sealing parts; Restored indicators: Pipeline pressure resistance reaches 35MPa with zero leakage; Customer feedback: Sealing system maintains stable performance in high-temperature dusty environments.

Case 4: Shengli Oilfield, 4017AC-122 Top Drive

Operating load: 3400kN variable drilling load; Fault phenomenon: Clutch transmission jitter caused by worn shaft assembly; Repair scheme: Replace 602-29-0 jaw clutch shaft and guide plate; Restored indicators: Transmission power output synchronous and stable, no jitter during load switching; Customer feedback: Mechanical transmission efficiency fully restored, equipment failure frequency significantly reduced.

5. Technical FAQ

6. Professional Procurement & Technical Reference Guidance

This serialized Canrig 4017AC-122/6027AC-939 top drive spare parts set provides standardized production benchmarks and systematic fault-solving technical references for global oilfield drilling and equipment maintenance teams. Every batch of products undergoes strict dimensional calibration, hydraulic pressure testing and electrical performance verification to ensure full interchangeability with original equipment parts. With reliable anti-vibration, anti-corrosion and high-temperature resistant performance, these professional-grade components effectively resolve common on-site equipment faults, reduce unplanned operational downtime and lower long-term maintenance costs. Users can select targeted spare parts according to actual equipment model, operating load and field working environment to sustain long-term stable and efficient operation of Canrig 275-ton top drive systems.
