BPM-DQ70BSC Top Drive & TDS System Components Supply (P/N: 9703340000, 5126000560, 4807101010)

Introduction

This document focuses on supplying high-quality, compatible components specifically designed for BPM-DQ70BSC top drives, TDS systems, and their supporting hydraulic power units (HPU). Our product range covers over 60 core components, including explosion-proof valves, sensors, hydraulic cylinders, seals, hoses, and mechanical parts, with key part numbers such as 9703340000 (Upper IBOP), 5126000560 (Explosion-Proof Magnetic Valve), 4807101010 (25L Rubber Bladder), and 5126000441 (Lubricating Oil Pump). We mainly serve oilfield drilling companies, on-site maintenance teams, and equipment repair workshops—our core goal is to solve the most painful problems in oilfield operations: unplanned downtime caused by component failure, high maintenance costs from mismatched parts, and safety hazards from low-quality replacements. All components are manufactured in strict compliance with API 6A, API 7K, and ATEX standards, and are fully compatible with BPM-DQ70BSC top drives and TDS systems, including those matched with National Oilwell Varco Blak-Jak Washpipe Cartridge systems (P/N 80506100). Backed by professional manufacturing experience, each batch of products undergoes 100% factory inspection, with exclusive test data to ensure reliability, helping customers minimize downtime and reduce maintenance costs.

Product Overview

Core Product Categories & Functional Descriptions

Our components are categorized by their functional roles in BPM-DQ70BSC top drives and TDS systems, each engineered to address specific on-site pain points:

• Explosion-Proof Electrical & Instrument Components: Including MB330.0-40MPA explosion-proof pressure transformer (P/N 3808000120) and GW200A oil temperature sensor (P/N 3808000072), which provide accurate pressure and temperature data in flammable and explosive oilfield environments, avoiding safety accidents caused by inaccurate monitoring. The explosion-proof magnetic valve (P/N 5126000560) meets ATEX certification, ensuring stable operation under 24V DC power supply without leakage or misoperation.

• Hydraulic Components: TDS-specific valves (P/N 5126000500, 5126040100) control oil flow and pressure, solving the problem of unstable hydraulic system operation; counterbalance cylinders (P/N 9705221100) and link tilt cylinders (P/N 9705227200) bear loads up to 3500kN, with a service life of 8,500 working hours, 2,500 hours longer than ordinary alternatives. The 1.5KW hydraulic cooling fan motor (P/N 3101030320) maintains system temperature, preventing overheating failures.

• Seals & Sealing Components: BPM-DQ70BSC-specific O-rings (P/N 5303001830, 5303001820) and sealing beads (P/N 5304010040) are made of high-temperature and oil-resistant fluororubber, withstanding temperatures up to 130℃ and pressure up to 45MPa, eliminating oil leakage—a common fault in hydraulic systems.

• Mechanical & Structural Components: The 40CrMnMoA spindle (P/N 9701000001) and brake disc (P/N 9702012003) are made of high-strength alloy steel, with tensile strength ≥ 850MPa, avoiding breakage during high-load drilling. Upper and lower IBOP (P/N 9703340000, 9703320000) ensure safe well control, preventing wellbore overflow.

• Filters & Auxiliary Tools: Strainers (P/N 5126000980) and filter elements (P/N 5126070070) filter impurities as small as 8μm, reducing wear on hydraulic components; nitrogen filling tools (P/N FPU-1-250F250F25G11A3K) and pocket pressure measures (P/N SMB20-2-250/400BAR) facilitate on-site maintenance, saving repair time.

Structural Features

All components adopt a modular and precision-machined design, making installation and disassembly quick and easy—reducing on-site maintenance time by 35 minutes per component on average. Key structural advantages include: precision-machined sealing surfaces (surface roughness ≤ 0.6μm) to ensure tight sealing; corrosion-resistant coating on external components to resist salt spray and humidity in offshore and desert oilfields; and reinforced load-bearing structures for mechanical parts, such as the brake hub (P/N 9702012004) made of 42CrMo steel, which can withstand 1120N·m torque without deformation. Additionally, all electrical components use flame-retardant materials, complying with EX d IIB T6 explosion-proof standards, ensuring safety in flammable environments.

Applicable Working Conditions

Our components are fully adapted to the harsh working conditions of oilfield operations, including onshore desert oilfields, offshore platforms, and high-temperature, high-pressure (HTHP) wells. They can operate stably in temperature ranges from -45℃ to 130℃, pressure up to 45MPa, and humidity up to 98%. Whether it’s the extreme temperature differences of desert oilfields or the high salt spray of offshore platforms, our components maintain reliable performance, ensuring continuous operation of BPM-DQ70BSC top drives and TDS systems. They are also compatible with National Oilwell Varco Blak-Jak Washpipe Cartridge systems, meeting the needs of mixed-equipment operations.

We supply the following spare parts:

On-Site Fault Maintenance Cases

Below are 4 real on-site maintenance cases, showing how our components solve practical problems and gain customer recognition:

Case 1: Shengli Oilfield, BPM-DQ70BSC Top Drive

Location: Shengli Oilfield, Shandong; Equipment model: BPM-DQ70BSC top drive; Load: 3200kN drilling load; Fault: Upper IBOP (old part) failed to close, risking wellbore overflow. Our solution: Replace with Upper IBOP (P/N 9703340000). After repair: IBOP closing time shortened to 1.5 seconds, pressure resistance up to 40MPa, no failure in 7 months. Customer feedback: "The replacement IBOP is highly compatible, easy to install, and effectively ensures well control safety, avoiding potential accidents."

Case 2: Bohai Offshore Oilfield, TDS HPU

Location: Bohai Offshore Oilfield; Equipment model: TDS HPU; Load: 1800kN hydraulic load; Fault: Hydraulic oil leakage due to worn O-rings (old parts), system pressure dropped to 18MPa. Our solution: Replace with BPM-DQ70BSC O-rings (P/N 5303001830, 5303001820). After repair: System pressure stabilized at 32MPa, no leakage for 9 months, reducing oil loss by 200L. Customer feedback: "The seals are durable and oil-resistant, perfectly adapting to the high-humidity offshore environment, saving maintenance costs."

Case 3: Tarim Desert Oilfield, BPM-DQ70BSC Top Drive

Location: Tarim Desert Oilfield, Xinjiang; Equipment model: BPM-DQ70BSC top drive; Load: 3600kN; Fault: Spindle (old part) fractured during high-load drilling, causing 8-hour downtime. Our solution: Replace with 40CrMnMoA spindle (P/N 9701000001). After repair: Spindle torque resistance reached 1200N·m, continuous operation for 1200 hours without failure, drilling efficiency improved by 15 meters per day. Customer feedback: "The spindle is strong and wear-resistant, adapting to the large temperature differences in the desert, significantly reducing downtime."

Case 4: Changqing Oilfield, TDS Gearbox

Location: Changqing Oilfield, Shaanxi; Equipment model: TDS gearbox; Load: 2500kN; Fault: Oil temperature exceeded 78℃, gearbox overheated due to faulty oil temperature sensor (old part). Our solution: Replace with GW200A oil temperature sensor (P/N 3808000072) and gear box oil filter (P/N 5126001230). After repair: Oil temperature stabilized at 58℃, gearbox service life extended by 1,800 hours, no overheating faults. Customer feedback: "The sensor provides accurate data, and the filter effectively purifies oil, ensuring stable gearbox operation."

Maintenance & Operation Tips

Our engineers summarize practical on-site maintenance tips to extend component service life and reduce failures, based on years of oilfield experience:

• Hydraulic valves & cylinders: Check oil cleanliness every 450 working hours; replace hydraulic oil every 1400 working hours. Do not use unqualified oil, as it will wear valve cores and cylinder walls—our engineers remind that using matching oil can extend component life by 3,000 hours.

• Seals: Inspect for aging or deformation every 280 working hours; replace seals if they become hard or cracked. Apply special lubricant before installation to avoid damage during assembly—this simple step reduces seal failure by 60%.

• Explosion-proof components: Keep connectors clean and dry; check cable connections every 380 working hours. Do not use non-explosion-proof tools near these components, as it may trigger safety hazards. Regularly check explosion-proof shells for damage.

• Mechanical parts: Apply grease to spindles, bearings, and rollers every 180 working hours; check for loose fasteners. For IBOP, test closing performance every 10 days to ensure it can work normally in emergencies.

FAQ (Frequently Asked Questions)

Procurement Guide & Commitment

We are committed to providing high-quality, compatible, and cost-effective components for BPM-DQ70BSC top drives, TDS systems, and their supporting equipment. All products are manufactured with strict quality control, with a 100% factory inspection pass rate and exclusive test data for each batch—such as 10,000 cycles of pressure testing for valves and 8,500 working hours of service life testing for mechanical parts. We cover all components listed (including P/N 9703340000, 5126000560, 4807101010, etc.), meeting your one-stop procurement needs. Whether you need regular replacement parts, emergency repair components, or professional technical guidance, we can provide reliable services. If you are looking for components that reduce downtime, lower maintenance costs, and ensure operational safety, please contact us to confirm the model and part number. We will provide a detailed quotation and product parameter manual, focusing on long-term cooperation to support your oilfield operations.
