BK, YX, TK Series Hydraulic Brake and Electro-Hydraulic Control Core Components

1. Core Application Purpose & Target User Demand

This complete set of BK brake mechanical parts, YX hydraulic sealing and cylinder components, TK control valve assemblies and supporting PSZ75B actuating mechanisms, EXX explosion-proof electrical boxes and detection instruments is professionally manufactured for heavy-duty electro-hydraulic brake systems of onshore oilfield drilling and workover rigs. It precisely serves oilfield field maintenance engineers, equipment overhaul teams and industrial parts procurement personnel, solving common industrial pain points including inaccurate hydraulic proportional control, brake cylinder operation jitter, sealing aging leakage, unmonitored oil temperature and pressure, and unsafe electrical operation in explosive dust environments. All components comply with GB national mechanical standards and petroleum industry safety specifications, with operational stability verified through 9000 hours of continuous field endurance testing. This product suite provides standardized procurement calibration benchmarks and actionable on-site fault resolution schemes, meeting dual core demands of standardized parts batch replacement and professional electro-hydraulic system technical maintenance.

2. Product Introduction

This full supporting portfolio covers all core functional, wearable and control accessories for integrated electro-hydraulic brake systems. It includes YX series copper bushes, pistons, cylinder covers, guide bands and multi-specification sealing rings, BK series service and emergency caliper cylinder assemblies, steel backings, adjusting screws, clevis pins and baffle plates. The lineup is equipped with TK brake valves, BK-F-G3 and YX-F-G3 globe valves, BK-DC-05 electro-hydraulic proportional valves and PSZ75B actuating mechanisms. It also integrates YW2-150 oil level temperature gauges, YN60-III pressure gauges, HA050200 quick couplings, EXX explosion-proof electric boxes and full sets of GB standard fasteners and washers. Every accessory adopts precision machining and anti-corrosion heat treatment, featuring high assembly consistency and structural interchangeability for oilfield hydraulic brake system daily maintenance and complete equipment overhaul.

3. Core Functional Description

3.1 Precise Electro-Hydraulic Brake Control

BK-DC-05 electro-hydraulic proportional valves and PSZ75B actuating mechanisms form an intelligent hydraulic control unit, solving the pain point of unstable braking torque output caused by traditional mechanical control deviation. Matched TK brake valves and globe valves ensure accurate hydraulic circuit switching, maintaining consistent braking response under variable heavy-load working conditions.

3.2 Real-Time Operating Condition Monitoring

YW2-150 oil level temperature gauges and YN60-III 0-16MPa pressure gauges achieve real-time monitoring of hydraulic system operating parameters. This configuration eliminates hidden faults such as high-temperature oil degradation and insufficient system pressure that cannot be detected in time, effectively improving overall operational safety of hydraulic systems.

3.3 Reliable Sealing & Explosion-Proof Protection

BK-SR and YX series sealing rings and guide bands build full-circuit hydraulic sealing protection to prevent medium leakage and dust invasion. EXX explosion-proof electric boxes meet field hazardous environment safety standards, avoiding electrical safety risks caused by spark leakage during equipment operation.

4. Structural Characteristics

All accessories adopt modular standardized structural design with unified industrial assembly tolerances, supporting rapid on-site disassembly and replacement without secondary calibration. Core caliper cylinder and piston components adopt high-pressure resistant integral forging technology, with strong deformation resistance under long-term hydraulic impact. Copper bush and guide band structures reduce internal friction loss, while adjusting screws and baffle plates support precise gap calibration. Explosion-proof electrical configuration and high-strength sealing structure adapt to extreme oilfield working conditions, greatly improving system operational stability and safety.

5. Applicable Working Conditions

This series of electro-hydraulic brake components is applicable to onshore oilfield drilling rigs, workover equipment and heavy hoisting machinery electro-hydraulic control and braking systems. It stably adapts to harsh open-air working environments with ambient temperatures ranging from -25℃ to 70℃, high dust concentration and flammable gas hazards, maintaining stable hydraulic control, braking performance and electrical safety under long-term intermittent heavy-load cyclic operation.

6. On-site Maintenance Suggestions (Engineer Practical Experience)

Summarized from frontline oilfield maintenance practice, hydraulic cylinder sealing parts and copper bushes require inspection every 3 months and full replacement every 8 months to avoid friction attenuation and leakage. Pressure and temperature monitoring instruments need regular calibration to ensure accurate data feedback. Explosion-proof electrical boxes and valve groups should be cleaned and inspected periodically to prevent dust accumulation affecting control performance. Mismatched fastener installation is strictly prohibited to avoid structural gap deviation. Standardized maintenance can increase the continuous stable working duration of matched equipment by 3000 working hours compared with irregular maintenance modes.

We supply the following spare parts:

7. Field Fault Maintenance Cases

7.1 Hydraulic Pressure Instability Fault in Daqing Oilfield

Location: Daqing Oilfield, Heilongjiang; Equipment Model: Drilling rig electro-hydraulic brake system; Operating Load: 90% rated load; Fault Data: System pressure fluctuates 1.0MPa abnormally, braking force unstable; Repair Scheme: Replace aging BK-SR sealing ring and worn YX copper bush; Post-repair Index: Pressure maintains constant rated value, braking output uniform; Customer Feedback: Hydraulic system operates stably in long-duration heavy-load tasks.

7.2 Brake Cylinder Jitter Fault in Tarim Oilfield

Location: Tarim Oilfield, Xinjiang; Equipment Model: BK caliper cylinder assembly; Operating Load: full continuous load; Fault Data: Cylinder reciprocating jitter, delayed braking response; Repair Scheme: Replace deformed BK sleeve and aging piston assembly; Post-repair Index: Cylinder movement smooth, response time restored to factory standard; Customer Feedback: Braking sensitivity fully meets field construction requirements.

7.3 Parameter Monitoring Abnormity in Changqing Oilfield

Location: Changqing Oilfield, Shaanxi; Equipment Model: Hydraulic parameter monitoring system; Operating Load: 87% rated load; Fault Data: Inaccurate oil temperature and pressure data reading; Repair Scheme: Calibrate YW2-150 and YN60-III instruments, replace aging quick coupling; Post-repair Index: Monitoring data accurate and real-time; Customer Feedback: System fault early warning capability significantly improved.

7.4 Electrical Safety Hidden Danger in Shengli Oilfield

Location: Shengli Oilfield, Shandong; Equipment Model: Field brake electrical control system; Operating Load: intermittent heavy load; Fault Data: Dust accumulation inside electric box leading to potential safety hazard; Repair Scheme: Replace aging EXX explosion-proof box accessories and clean internal circuit; Post-repair Index: Electrical system fully meets explosion-proof safety standards; Customer Feedback: Field operation safety risk completely eliminated.

8. Product FAQ

9. Technical Standard & Procurement Guidance

All products are manufactured and inspected in strict accordance with GB5782-86, GB/T6173-2000 and JB industry authoritative standards, with complete field test data and safety certification to meet petroleum machinery explosion-proof and industrial-grade operation specifications. This full set of BK, YX, TK series and supporting electro-hydraulic brake components provides unified and standardized procurement parameter benchmarks for daily maintenance, parts renewal and overall overhaul of oilfield electro-hydraulic braking systems. It also acts as a professional technical reference for on-site operators to diagnose hydraulic pressure faults, cylinder jitter, monitoring deviation and electrical hidden dangers, guiding standardized disassembly, assembly and maintenance operations. Verified by long-term practical application in multiple major oilfields, the product portfolio delivers outstanding environmental adaptability, control precision and operational safety. Users can select targeted matching accessories according to actual equipment models, operating loads and fault characteristics to complete refined equipment maintenance, stabilize electro-hydraulic brake system performance and reduce overall equipment failure frequency. We provide standardized industrial-grade supporting parts for oilfield mechanical equipment renovation and routine maintenance, supporting users to realize standardized equipment operation and efficient fault maintenance.
