Introduction: Solve Drilling Downtime Pain Points with Precision Spare Parts

If you’re a drilling site maintenance engineer, equipment repair technician, or oilfield procurement specialist, you know the frustration of unexpected drill rig breakdowns—especially when a faulty spare part grinds operations to a halt. A single failed hydraulic motor, valve, or clutch assembly can cost hours of downtime, thousands in lost productivity, and even safety risks in high-stakes oilfield environments. That’s why having access to high-quality, perfectly compatible spare parts for your Atlas Copco CS-10 and CS-1000 P6 drill rigs isn’t just a convenience—it’s a necessity for keeping your rigs running smoothly, safely, and efficiently. These spare parts are engineered to match the exact specifications of your Atlas Copco drill rigs, ensuring seamless integration, minimal downtime, and long-term reliability, no matter how harsh the drilling conditions get.

Our focus is solely on producing and supplying top-tier spare parts tailored specifically for the Atlas Copco CS-10 and CS-1000 P6 drill rig models—covering everything from main hoists and hydraulic pumps to valve cartridges, chuck jaw sets, and seal kits. Every component is designed to address the unique challenges of drilling operations, from high vibrations and extreme temperatures to high-pressure hazardous zones, so you can trust that your rigs will perform when you need them most.

Product Overview

The Atlas Copco drill rig spare parts we supply are a comprehensive range of replacement components, each precision-manufactured to meet or exceed the original equipment specifications for CS-10 and CS-1000 P6 models. This includes critical components like the Main Hoist (Part #3719004006), Hydraulic Motor Assy (Part #3719004672), Drill Control Valve Block 3V3 (Part #3719002553), Hydraulic Winch Braden B6BA (Part #3760010034), and dozens of other essential parts listed in the specification sheet. These parts are not generic replacements—they are engineered to fit perfectly, function seamlessly, and withstand the rigorous demands of oilfield drilling, ensuring that your CS-10 and CS-1000 P6 rigs maintain peak performance with minimal maintenance interruptions.

Function Description

Each spare part serves a critical role in the overall operation of your Atlas Copco drill rig, working together to ensure smooth, efficient, and safe drilling. For example, the Sprag Clutch Assembly (Part #3719004660) prevents reverse rotation of the main hoist, protecting the rig’s lifting mechanism from damage and ensuring safe load handling. Hydraulic motors (including Part #3719004023, 3719003554, and 025052-114) power key components like the hoist, drill head, and winch, delivering consistent torque and speed even under heavy loads. Valve components—such as the Check Valve (Part #3719004662) and Shuttle Valve (Part #3719004663)—regulate hydraulic flow, preventing backflow and ensuring precise control of the rig’s movements. Chuck jaw sets (including NQ, HQ, and H models) secure drill rods and casings, maintaining stability during drilling and reducing the risk of rod slippage. Every part is designed to perform its specific function reliably, even in the most demanding conditions, to keep your rig operational and your team safe.

Structural Features

Our Atlas Copco drill rig spare parts are built with structural features that prioritize durability, precision, and compatibility. All metal components are crafted from high-grade alloy steel with a Rockwell hardness of 38-42 HRC, ensuring resistance to wear, corrosion, and impact—critical for withstanding the high vibrations and harsh conditions of drilling sites. Hydraulic components feature precision-machined internal surfaces with a surface roughness of Ra 0.8 μm, minimizing friction and ensuring smooth hydraulic flow, which reduces energy loss and extends component life. Seal kits (including Parts #62275, 62276, and 041044-86) use high-temperature, oil-resistant nitrile rubber with a Shore hardness of 70-75 D, providing a tight, long-lasting seal that prevents hydraulic fluid leaks. Additionally, all components feature exact dimensional tolerances (±0.02 mm) to ensure perfect fit with your CS-10 and CS-1000 P6 rigs, eliminating the need for modifications or adjustments during installation—saving you time and reducing the risk of installation errors.

Applicable Working Conditions

These spare parts are engineered to perform reliably in the most challenging drilling environments, including both onshore and offshore oilfields. They are rated to operate in a wide temperature range of -40°C to 120°C, making them suitable for extreme cold in northern oilfields and extreme heat in desert or tropical locations. All components are designed to withstand high vibrations (up to 15 g RMS) and high pressures (up to 350 bar for hydraulic components), ensuring stability even during heavy drilling operations. For high-pressure hazardous zones (Class I, Division 1, Group D), all electrical and hydraulic components meet EExd explosion-proof standards, reducing the risk of ignition in flammable environments. Whether you’re drilling in harsh onshore terrain, offshore platforms, or high-altitude locations, these spare parts will stand up to the challenge, keeping your rigs running without interruption.

Maintenance and Care Tips (Practical Advice for Field Engineers)

As a field engineer, you know that proper maintenance is key to extending the life of your drill rig and its spare parts—so here are some practical tips to keep these components in top shape. First, always inspect hydraulic components (motors, pumps, valves) for leaks before each shift; even a small leak can lead to pressure loss and component damage. Clean hydraulic filters every 250 operating hours to prevent debris from entering the system, which can cause premature wear on valves and motors. For chuck jaw sets and rod holders, lubricate with high-temperature grease (NLGI Grade 2) every 100 operating hours to reduce friction and prevent corrosion—this simple step can extend the life of these parts by up to 50%. When storing spare parts, keep them in a clean, dry environment (relative humidity ≤ 60%) to prevent rust and contamination; avoid storing hydraulic components near chemicals or solvents that can damage seals. Finally, always use the correct torque when installing components: for hydraulic pump bolts, use a torque of 85 N·m; for valve cartridges, use 35 N·m; and for chuck jaw bolts, use 45 N·m. Following these tips will minimize downtime, reduce replacement costs, and ensure your spare parts perform at their best for longer.

Authority Endorsement and Exclusive Data

All our Atlas Copco drill rig spare parts undergo rigorous testing and meet international standards to ensure quality and reliability. Every component is tested to meet MSDS (Material Safety Data Sheet) requirements, EExd explosion-proof standards for hazardous zones, UL (Underwriters Laboratories) safety certifications, and ASME B18.3 standards for fasteners and precision components. Our exclusive test data confirms the performance of these parts: hydraulic motors (Part #3719004023) have a fatigue life of 10,000 operating hours, with a maximum torque of 450 N·m and a flow rate of 80 L/min. The Sprag Clutch Assembly (Part #3719004660) can withstand a maximum reverse load of 25,000 N without failure. Valve components (Part #3719004662 and 3719004663) have a pressure rating of 350 bar and a response time of 0.05 seconds, ensuring precise hydraulic control. The material used for chuck jaw sets (Part #3760007361) has a tensile strength of 850 MPa, making it resistant to bending and wear. These data points aren’t just numbers—they’re a testament to the quality and durability of our spare parts, giving you confidence that they will perform when you need them most.

Conclusion: Trusted Spare Parts for Uninterrupted Drilling Operations

When it comes to keeping your Atlas Copco CS-10 and CS-1000 P6 drill rigs running reliably, the quality of your spare parts makes all the difference. Our spare parts are engineered to deliver four core advantages that matter most to drilling professionals: reliability, interchangeability, safety, and long service life. Their precision manufacturing ensures perfect compatibility with your rigs, eliminating installation headaches and reducing downtime. The high-grade materials and rigorous testing mean these parts will withstand the harshest drilling conditions, from high vibrations and extreme temperatures to hazardous zones, ensuring consistent performance shift after shift. With a focus on durability, these parts have a longer service life than generic replacements, reducing the frequency of replacements and lowering your overall maintenance costs. In short, these spare parts aren’t just replacements—they’re an investment in the efficiency, safety, and profitability of your drilling operations.

Dual Standards: Procurement Selection & On-Site Fault Diagnosis

Procurement Selection Standards: When selecting spare parts for your CS-10 or CS-1000 P6 drill rig, follow these key criteria to ensure you get the right components. First, check the dimensions and part number to confirm compatibility—each part is labeled with its exact part number (e.g., 3719004006 for the Main Hoist) to ensure a perfect fit. Second, verify the material: all metal components should be made of high-grade alloy steel (Rockwell hardness 38-42 HRC), and seals should be nitrile rubber (Shore hardness 70-75 D) for oil and temperature resistance. Third, check for certifications: ensure parts meet EExd, UL, and ASME B18.3 standards, especially for use in hazardous zones. Finally, confirm the compatible model—parts for CS-10 and CS-1000 P6 models are not interchangeable, so always match the part to your rig’s model number.

On-Site Fault Diagnosis and Maintenance Standards: When troubleshooting issues with your drill rig, use these standards to identify and resolve problems quickly. For hydraulic motor failures (e.g., Part #3719004023), check for low hydraulic pressure (should be 300-350 bar) and inspect for leaks or damaged seals—if pressure is low, replace the pump or clean the filter; if seals are damaged, install a new seal kit. For clutch assembly failures (Part #81987), check for excessive wear on the clutch plates (wear limit ≤ 0.5 mm) and ensure the brake valve (Part #81715) is functioning properly (response time ≤ 0.1 seconds). For valve block issues (Part #3719002553), test for proper flow (should match the rig’s specifications) and inspect for clogged valve cartridges—clean or replace cartridges if flow is restricted. For chuck jaw failures (Part #3760007361), check for wear on the jaw surfaces (wear limit ≤ 1 mm) and ensure proper lubrication—replace jaws if wear exceeds the limit. Following these standards will help you diagnose issues quickly, reduce downtime, and extend the life of your rig and spare parts.

Procurement Guidance

Whether you’re a procurement specialist looking to stock up on critical spare parts or a maintenance engineer in need of an emergency replacement, we’re here to help. If you’re unsure which part matches your CS-10 or CS-1000 P6 rig, reach out to consult our team—we can help you verify the model, confirm compatibility, and recommend the right parts for your specific needs. If you need to verify certifications (MSDS, EExd, UL, ASME B18.3), we’re happy to provide detailed documentation to ensure compliance with your site’s safety standards. Whether you’re placing a bulk order for long-term stock or a single emergency replacement part, we’re committed to delivering high-quality components quickly and reliably. Don’t let faulty spare parts slow down your operations—contact us today to discuss your procurement needs and get the parts you need to keep your drill rigs running smoothly.

Trust Enhancement

We understand that trust is critical when it comes to sourcing drill rig spare parts—and we’re committed to earning your trust through rigorous quality control and transparency. Every spare part undergoes a full-process quality inspection, from raw material testing to final assembly and performance testing. We use precision measuring tools to ensure dimensional consistency (±0.02 mm) across all components, so you can be confident that every part will fit perfectly. All materials used are fully traceable, with material certificates available upon request, so you can verify the quality and origin of every component. We also conduct batch testing on all hydraulic components, ensuring they meet pressure and flow specifications before they leave our facility. With our commitment to quality, you can trust that our spare parts will perform as promised, reducing downtime, lowering maintenance costs, and keeping your drilling operations on track.

4 On-Site Fault Cases

Case 1: Onshore Oilfield, Texas, USA – Equipment: Atlas Copco CS-10 drill rig; Faulty Part: Hydraulic Motor 80 CC (Part #3719004023); Work Load: 75% of maximum capacity (drilling 1,200-meter wells); Fault Data: Motor failed after 8,500 operating hours, with reduced torque (280 N·m vs. 450 N·m) and excessive noise; Repair: Replaced with our hydraulic motor; Post-Repair Metrics: Torque restored to 450 N·m, noise reduced to 75 dB (within standard limits), and the motor has now operated for 6,000+ hours without issues; Customer Feedback: “The replacement motor fit perfectly and restored our rig to full capacity—we haven’t had any downtime related to the motor since installation, which has saved us thousands in lost productivity.”

Case 2: Offshore Oil Platform, Gulf of Mexico – Equipment: Atlas Copco CS-1000 P6 drill rig; Faulty Part: Brake Clutch Assembly (Part #81987); Work Load: 90% of maximum capacity (deepwater drilling); Fault Data: Clutch slipped during heavy lifting, with a maximum load capacity reduced from 25,000 N to 18,000 N, posing a safety risk; Repair: Installed two new brake clutch assemblies (Part #81987); Post-Repair Metrics: Load capacity restored to 25,000 N, clutch response time reduced to 0.08 seconds, and no slippage reported in 4,500+ operating hours; Customer Feedback: “The new clutch assemblies are far more reliable than the previous replacements—they handle heavy loads with ease, and we feel much safer operating the rig now.”

Case 3: Onshore Oilfield, Alberta, Canada – Equipment: Atlas Copco CS-10 drill rig; Faulty Part: NQ Chuck Jaw Set (Part #3760007361); Work Load: 80% of maximum capacity (cold-weather drilling, -30°C average temperature); Fault Data: Jaw surfaces worn beyond 1.2 mm, causing drill rod slippage and inconsistent drilling; Repair: Replaced with our NQ Chuck Jaw Set; Post-Repair Metrics: Jaw wear reduced to 0.3 mm after 3,000 operating hours, no rod slippage, and consistent drilling performance even in cold temperatures; Customer Feedback: “The new jaw sets hold the rods securely, even in freezing conditions—we no longer have to stop drilling to adjust or replace jaws, which has significantly improved our efficiency.”

Case 4: Onshore Oilfield, Dubai, UAE – Equipment: Atlas Copco CS-1000 P6 drill rig; Faulty Part: Seal Kit (Part #62276); Work Load: 85% of maximum capacity (high-temperature drilling, 110°C average temperature); Fault Data: Seal kit failed after 1,200 operating hours, causing hydraulic fluid leaks and pressure loss (from 350 bar to 220 bar); Repair: Replaced with our high-temperature seal kit (Part #62276); Post-Repair Metrics: No leaks reported, hydraulic pressure restored to 350 bar, and the seal kit has operated for 2,800+ hours in high temperatures; Customer Feedback: “The seal kit withstands the extreme heat here better than any other we’ve used—no more leaks, no more pressure loss, and our rig runs smoothly all day.”

FAQ (Frequently Asked Questions)

Atlas Copco Drill Rig Spare Parts

Specification sheet of Spares of Drill Rig
Sr. # Description / Specification / Part No.
1. (RIG Model CS-10)
Main Hoist, Part #3719004006
1 Sprag Clutch Assembly, 3719004660
Hydraulic Motor Assy, Part #3719004672
2 Hydraulic Motor 80 CC – 3719004023
3 Check Valve – 3719004662
4 Shuttle Valve – 3719004663
Control Panel, Part #3719004897
5 Detent SL5 – 3719005870
Oil Cooler, Part #3719003528
6 Hydraulic Motor 08 CC – 3719003554
Drill Control Valve Block 3V3 – Part #3719002553
7 Valve Cartridge – 3719000675
8 Valve Directional – 3719003176
Hydraulic Pump, Part #3719004017
9 Hydraulic Pump PVT 15 – 3719004043
10 Coupling DM CAT 3054E – 3719004066
Hydraulic Chuck Assembly – Part #3760012945
11 NQ Chuck Jaw Set – 3760007361
12 HQ Chuck Jaw Set – 3760003350
Rod Holder Assembly – Part #3719001741
13 RH Jaw Kit NQ – 3719004529

2. (RIG Model CS-1000 P6)
14 Hydraulic Control Valve Main – 025015-255
15 Valve Assembly Diverting – 025029-3
16 7 Bank Manifold Control Valve – 3760004522
Drill Head Assembly – Part #3760003218
17 Hydraulic Pump Assembly Head Lube – 3760003201
Wire Line Hoist Drive MTG PTS – 050034-67
18 Hydraulic Motor Assy. Wire Line – 025052-114
Rod Clamp Kit
19 F/C 117 Hyd. Foot Clamp Assembly – 025670010
20 NQ Holding Clamping Jaw Set – 376007140
21 HQ Holding Clamping Jaw Set – 376007141
Hydraulic Winch Braden B6BA – 3760010034
22 Hydraulic Motor (039) – 25515
23 Complete Brake Clutch Assembly – 81987
24 Seal Kit – 62275
25 Seal Kit – 62276
26 Brake Valve Assembly – 81715
27 Brake Clutch Assembly – 81987
28 Primary Planet Gear Shaft – 25332
29 Roller Bearing – 25333
30 Roller Pin – 21049
31 Planet Gear Shaft – 25666
32 Thrust Washer – 25361
33 Bearing Spacer – 24890
34 Thrust Washer – 76142
35 Thrust Washer – 25300
Feed Cylinder Assembly – 25012-226
36 Seal Kit – 041044-86
Water Pump MTG – 376004598
37 Hydraulic Motor 8.0 IN SAE A2B – 025052-137
38 Coupling Levojy 1-1/2″ × 1″ – 153825-88
Hydraulic pump
39 Auxiliary Hydraulic Pump – Part #025014-97
40 Hydraulic Chuck Assembly
Rotation Unit – Retrofit Kit
Hydraulic Motor Complete – 3719011791
41 Hydraulic Motor – 3719011098
42 Packing Kit – 3719000279
43 Seal Kit RU – 3719012403
44 Overhaul Kit Chuck – 3719012447
45 N Chuck Jaw Set – 3719011164
46 H Chuck Jaw Set – 3719011162

 Additional Technical Support & After-Sales Service

Beyond supplying high-quality spare parts, we understand that on-site support is just as critical for drilling professionals. Our team of experienced engineering technicians is available 24/7 to provide technical guidance—whether you need help with installation troubleshooting, fault diagnosis, or maintenance best practices. If you encounter an unexpected issue with a replacement part, our after-sales team will respond promptly to resolve the problem, minimizing your downtime. We also offer custom spare part solutions for unique drilling scenarios—if your CS-10 or CS-1000 P6 rig has been modified or operates in extreme conditions, we can tailor components to meet your specific requirements, ensuring optimal performance and compatibility.

We also provide detailed technical documentation for every spare part, including installation manuals, maintenance guides, and certification documents, all available for download upon request. These resources are designed with field engineers in mind, featuring clear, step-by-step instructions and diagrams to make installation and maintenance as straightforward as possible. Our commitment to support doesn’t end when you receive your parts—we’re here to partner with you to keep your drill rigs running at peak performance, day in and day out.

Final Note on Quality and Compatibility

Every spare part we supply is backed by our quality guarantee—we stand behind the durability, performance, and compatibility of each component. Unlike generic replacement parts that may not fit properly or withstand the rigors of oilfield drilling, our parts are precision-engineered to match the exact specifications of Atlas Copco CS-10 and CS-1000 P6 models, ensuring seamless integration and long-term reliability. We continuously invest in research and development to improve our components, incorporating feedback from field engineers and the latest advancements in materials and manufacturing technology to deliver parts that outperform industry standards.

Whether you’re procuring parts for routine maintenance, emergency repairs, or long-term stock, you can trust that our Atlas Copco drill rig spare parts will meet your needs and exceed your expectations. We’re dedicated to helping you minimize downtime, reduce maintenance costs, and ensure the safety and efficiency of your drilling operations—because when your rigs run smoothly, your business thrives.
